XTIUM FAMILY

XTIUM2 FAMILY

LINEA HS2

Drawing on Teledyne’s four decades of industry leading expertise, the all new Linea™ HS2 camera series represents a significant breakthrough in next generation TDI technology. Designed for ultra-high-speed imaging in light starved conditions, it delivers exceptional image quality with 16k/5 µm resolution and boasts an industry leading maximum line rate of 1 Megahertz, or 16 Gigapixels per second data throughput.

LINEA LITE

Linea Lite makes line scan more accessible than ever. Designed with performance in mind, this camera offers superior color fidelity with 2k, 4k and 8k resolution and line rates from 12.5 to 50 kHz, with a GigE Vision® interface.

LINEA

Linea line scan cameras deliver the performance and features usually found in high-end cameras at an attractive price point. Based on advanced CMOS line scan technology, Linea GigE cameras have a 2k or 4k single line 7.04 µm x 7.04 µm pixel array. With excellent sensitivity and speed, Linea surpasses the requirements of demanding applications —such as materials grading and inspection, transportation safety, and general purpose machine vision.

TETRA

The Tetra camera family offers a high performance-to-cost ratio through its 2.5 GigE Vision interface, which provides 2.5x bandwidth of GigE in data transmission over long cable lengths. Available in 2k, 4k, and 8k resolutions, the camera comes in both monochrome or color versions, with power consumption of under 6 watts. Monochrome models deliver excellent image quality with options for single line monochrome or dual line HDR mode, while the color models provide true trilinear red, green and blue colors without any data interpolation.

LINEA2

The brand new Linea2 family takes your system to the new level with impressive performance and value, offering 5x the bandwidth of our Linea family with a 5GigE interface. The Linea2 line scan cameras are powered by our very own Teledyne quadlinear sensor, extending detection capability using RGB + NIR multispectral imaging tech

LINEA ML

The Linea ML brings leading edge CMOS technology that is faster than ever, with affordable multiline architecture that enables the newest, most powerful inspection techniques including HDR, color and multispectral analysis, and multi-field imaging (single-pass bright/darkfield). With a native fiber optic interface for easy, low-cost long cabling, the Linea ML opens new horizons in inspection.

LINEA HS

The all new Linea HS™ delivers line rates up to an incredible 400 kHz at 32k resolution — over 13 Gpixels/sec via CLHS interface. With up to 128 TDI stages (plus an extra 64 in HDR mode) for unmatched sensitivity and incredibly low noise, Linea HS excels in the highest speed, lowest light applications.

LINEA SWIR

Like all Lineas, Linea SWIR shares the robust build quality and advanced functionality that is part of Teledyne DALSA’s unmatched line scan heritage. Linea SWIR is packed with features to make your machine vision job easier, including high speed, high sensitivity, cycling mode, and programmable I/Os. The versatile Linea SWIR is ideal for applications such as optical sorting, solar panel inspection, and general purpose machine vision.

AxCIS

AxCIS™ is a fully integrated line scan imaging module which combines sensors, lenses, and lights all-in-one. This Contact Image Sensor (CIS) is easy-to-use and offers a lower system cost for many demanding machine vision applications as well as superior signal-to-noise ratio and a Camera Link HS SFP+ fiberoptic interface. AxCIS can fit anywhere in your system, even with limited vertical clearance and it’s easy to install, with no complex alignment or calibration required and a single 24v power supply. Monochrome and color models are available now.

PIRANHA4

Powered by our latest high performance CMOS line scan imagers, the Piranha4 offers resolutions from 2k to 8k pixels in a variety of pixel sizes to let you inspect and detect with unrivalled precision, speed, and responsivity.

GENIE NANO 10GIGE

Engineered for imaging applications that require next generation speeds and resolutions, the all-new Genie Nano-10GigE series is an easy replacement for gigabit ethernet cameras built into current vision systems that rely on the existing GigE Vision interface standard. The new Genie Nano-10GigE models feature the brand new 10Gbps (10GBASE-T) link speed, delivering next generation speeds without compromise.

GENIE NANO GIGE

Introducing Genie Nano, a CMOS GigE camera that redefines low cost performance. Genie Nano starts with industry leading CMOS sensors and adds proprietary camera technology for breakthrough speed, a robust build quality for wide operating temperature, a three-year warranty and an unmatched feature set — all at an incredible price.

GENIE NANO-CL

Instead of choosing between performance, feature set, reliability, and cost, Teledyne’s Genie Nano-CL cameras offer a series CMOS area scan cameras with all of that in mind. Built for industrial applications, the Genie Nano-CL is designed for long-term performance.

GENIE NANO 5GIGE

Introducing the Genie Nano-5GigE, a GigE Vision CMOS area scan camera that redefines high performance. Genie Nano starts with industry leading image CMOS sensors from 3.2 to 45 megapixel and adds proprietary camera technology for breakthrough speed, a robust build quality for wide operating temperature, and an unmatched feature set — all at an incredible price. Teledyne DALSA’s proprietary TurboDrive™ technology allows Genie Nano to deliver its full image quality at faster frame rates — often 150% or higher.

GENIE NANO-CXP

Introducing Genie Nano-CXP, a camera designed for full-throttle performance. Genie Nano-CXP builds on Nano's proven, industry leading reputation and leverages a CoaXPress 6Gbps interface to deliver the maximum throughput from leading-edge high-resolution CMOS image sensors.

In resolutions from 16 to 67 megapixels, Genie Nano-CXP ensures robust build quality, wide operating temperature, and an unmatched feature set — all at an incredible price.

FALCON4-CLHS

For true high-performance imaging, turn to the Falcon4-CLHS camera series. Using Teledyne’s advanced CMOS architectures, Falcon4-CLHS cameras offer unique, unprecedented capabilities for large area, high-resolution, high-speed imaging. Models range from 11.2 megapixels to 86 megapixels, with frame rates up to 609 fps.

Z-TRAK LP1

1024 Measurements / profile

• In-line 3D height measurements

• World measurement units

• Up to 3 KHz

Z-TRAK LP2C

4096 Measurements / profile

• In-line height measurements

• Wide selection of red and blue (405 nm) laser models

• Over 5 KHz

Z-TRAK2

2048 Measurements / profile

• In-line 3D measurements

• 1, 2.5 and 5 GigE interface

• AOI: up to 45 KHz

PCI Express Gen3 Platform

• Flexibility and scalable: Supports popular machine vision camera interface standards

• Zero CPU usage, ready to use images

• Zero copy image, real-time image stitching from multiple cameras

PCI Express Gen2 Platform

• Flexibility and scalable: Supports popular machine vision camera interface standards

• Zero CPU usage, ready to use images

• Zero copy image, real-time image stitching from multiple cameras

SAPERA LT SDK

Teledyne DALSA Image Acquisition and Control Libraries for Machine Vision

• Supports multiple MV standars: CameraLink, Camera Link HS, CoaXpress, GigE Vision & USB3 Vision

• Integrated support of Trigger-to-Image Reliability and patented TurboDrive technology

• Supports Teledyne FrameGrabbers, Area scan, Line scan and Laser Profiler Cameras

SAPERA PROCESSING

Image Processing & AI-Enabled Application Development Library

• Hardware & image acquisition SDK independent, image processing/analysis and artificial intelligence library

• Including: Barcode, Search, OCR, Blob analysis, Measurement and AI functions like Detection, Segmentation and Classification

• Direct support and demos for both Sapera LT and Spinnaker SDK and compatible with third party acquisition SDKs

ASTROCYTE

Graphical User Interface for Rapid Machine Vision Application Development

• Intuitive controls for spectral overlay, peak find, view, and playback

• Powerful built-in math engine analyses image and spectra data in real-time

• Automated Wavelength and Intensity Calibration

SHERLOCK

Image Acquisition and Processing Development through Graphical User Interface

• Develop and debug inspections quickly and reliably

• Including: Barcode, OCR, Blob analysis, Measurement and AI functions like Detection, Segmentation and Classification

• Supports Teledyne FrameGrabbers, Area scan, Line scan and Laser Profiler Cameras
