The Schneider Group specializes in developing and producing high-performance lenses for film, cinema projections lenses, as well as industrial optics and precision mechanics.

SCHNEIDER-KREUZNACH FILTERS

UV-IR-CUT / PROTECTION

DUAL BANDPASS FILTER

BANDPASS SERIES

NARROW BANDPASS

• High transmission

Low reflection

Cost effective protection of sensible units

High reproducibility

• High transmission (average 95 %)

Low wavelength tolerance +/- 1 %

Cost effective protection of sensible units

RoHS conform

• Average transmittance 95 %

Steep slopes

Wavelength tolerance +/- 1 %

Ultra low reflection

Deep blocking / high OD

• Average transmittance 90 %

Steep slopes

Wavelength tolerance +/- 3 %

Deep blocking / high OD

SHORTPASS

• Average transmittance 95 %

Steep slopes

Wavelength tolerance +/- 1 %

Ultra low reflection

Deep blocking / high OD

LONGPASS

NEUTRAL DENSITY

COLOUR

POLARIZER

• Average transmittance 95 %

Steep slopes

Wavelength tolerance +/- 1 %

Ultra low reflection

Deep blocking/ high OD

• Insensitive to angle of incidence

Decrease brightness without changing depth of field

Stackable, combine ND filters to achieve OD needed

Even attenuate avoid effects on color balance

• AR coating available

Insensitive to angle of incidence

Large CA, absence of vignetting

Improve contrast

Isolate colors

• Reduce reflections, increase contrast

High extinction ratio

Edge sealed available on request

Pre-cut custom shapes for polarizing films on request

SCHNEIDER-KREUZNACH LENSES

XENON-OPAL 1,1 C-MOUNT

XENON-TOPAZ 1,1 C-MOUNT SERIES

1,3" C-MOUNT 12 MP SERIES

1,3" TFL-MOUNT 12MP

• 12 mm C-mount lens for up to 12 megapixels, 1.1" sensors, 3 μm pixel size

Max. chief ray angle of 6°

Vibration insensitivity for stable imaging performance all over the sensor

Optimized for 0.3 to 1.5 m working distance

400 to 1000 nm broadband AR-coating

• High-resolution optics for up to 12 megapixel sensors

Broadband coating (400 - 1,000 nm)

Optional ruggedized for harsh surroundings

Vibration insensitive for stable imaging performance

Focus and iris setting lockable

• Anti-shading for sensor sizes up to 1.3" (image circle 24 mm)

Designed for up to 12 megapixel sensors with micro-lenses

High resolution optics 400 - 700 nm (VIS) /

700 - 1,000 nm (NIR)

• Very high MTF across the entire sensor

Robust mechanics for industrial environment

Focus and iris setting lockable

• Anti-shading for sensor sizes up to 1.3" (image circle 24 mm)

High-resolution optics 400 - 700 nm (VIS) /

700 - 1,000 nm (NIR)

Very high MTF across the entire sensor

Robust mechanics for industrial environment

1,3" C-MOUNT 3-5MP

• High-resolution optics

Highest optical imaging performance even with smallest pixel sizes

Broadband coating (400 - 1,000 nm)

Compact and low weight

Vibration insensitivity for stable imaging performance

Focus and iris setting lockable

1,3 TFL-MOUNT 3-5 MP SERIES

1" C-MOUNT

XENON-RUBY 1/1,8" C-MOUNT

2/3" C-MOUNT 5 MP SERIES

• Anti-shading for sensor sizes up to 1.3" (image circle 24 mm)

High-resolution optics 400 - 700 nm (VIS) /

700 - 1,000 nm (NIR)

Very high MTF across the entire sensor

Robust mechanics for industrial environment

• Broadband coating (400 - 1,000 nm)

Compact and low weight

Vibration insensitivity for stable imaging performance

Focus and iris setting lockable

Optional with motorized p-iris

• For cameras with up to 10 MP sensors

Robust mechanics for rough industrial environment

Transmission 400 - 1,000 nm (VIS - NIR)

Compact and low weight

Designed for Sensors up to 1/1.8” (9 mm)

Focus and iris setting lockable

• Highest optical imaging performance even with smallest pixel sizes from 2.5 μm

Excellent MTF across the entire sensor size

Broadband coating (400 - 1,000 nm)

Compact and low weight

Vibration insensitivity for stable imaging performance

Focus and iris setting lockable

2/3" C-MOUNT 3-5MP

• Vibration insensitivity for stable imaging performance

• Optional ruggedized

Focus and iris setting lockable

• Optional with motorized p-iris

Broadband coating (400 - 1,000 nm)

FAST LENSES SERIES

XENON-EMERALD LARGE SENSOR

XENON-SAPPHIRE LINE SCAN

XENON-ZIRCONIA LINE SCAN

• Very high relative aperture of 0.95

Compact full metal mount

Vibration insensitivity for stable imaging performance

Focus and iris setting lockable

• 43.2 mm image circle

for up to 29 MP sensors

Robust mechanics for rough industrial environment

Constant MTF over the entire image field

Focus and iris setting lockable

• For 16k line scan cameras (57.3 mm length/ pixel sizes 3.5 μm and 82 mm length/ pixel size approximately 5 μm)

For 12k line scan cameras (62.5 mm length/ pixel sizes approximately 5 μm)

High resolution optics 400 - 1,000 nm

Robust mechanics for industrial environment

Vibration insensitive

Focus and iris setting lockable

• For 12k line scan cameras (62.5 mm length/ pixel sizes approximately 5 μm) and 16k (82 mm length/ pixel size approximately 5 μm)

Very high optical image quality in the large sensor range

Vibration-insensitive for stable optical performance

Lockable distance and aperture settings

Industry-compatible V-mount interface

Reliability and constant quality due to 100 % quality control

XENON-DIAMOND LINE SCAN

• For line scan cameras 12k (62.5 mm length/ pixel sizes approximately 5 μm) and 16k (82 mm length/ pixel sizes approximately 5 μm)

Very high optical image quality for large sensors

Vibration-insensitive for stable optical performance

Lockable distance and aperture settings

Industry-compatible V-mount interface

Reliability and constant quality due to 100 % quality control

V38-LINE SCAN MACRO SYSTEM

UNIFOC SYSTEM

MACRO VARON SERIES

SWIRON SERIES

• Very high optical image quality in the large sensor range

Vibration-insensitive for stable optical performance

Reverse position of the lens possible to enlarge the

magnification range

Lockable distance and aperture settings

100 % quality control guarantees reliability and constant quality

Low maintenance requirements, therefore high system availability

• Excellent optical imaging performance when using large

sensors

100 % quality control guarantees reliability and constant quality

Low maintenance requirements, therefore high system reliability

• Developed for high-resolution 12k line scan applications with pixel sizes from 3.5 μm up to 5 μm

Focus and iris setting lockable

• High resolution optics 400 - 1,000 nm

Very high optical image quality in the large sensor range

• Designed for 800 - 1,800 nm

High transmission

Distortion less than 1 %

Usage of highly transparent glass for SWIR range

Special lack inside the lens to minimize light scatter in the SWIR range

TELECENTRIC SERIES

• Bilateral telecentric

The lenses can be focussed on the image side in a range of +/- 3 mm

Numeric aperture of 0.14 or 0.13
